CyberPower Online Series OL2000ERTXL2U Rack/Tower 2000/1800VA Pure Sine Wave UPS
Model
OL2000ERTXL2U
| Location | Availability |
|---|---|
Online (Delivery) | Preorder |
Notting Hill (Pickup) | Preorder |
Preston (Pickup) | Preorder |
West Melbourne (Pickup) | Preorder |
$1,979.00
Specifications
GENERAL
Phase
| Single Phase |
Form Factor
| Rackmount, Tower |
UPS Topology
| Online Double Conversion |
Energy Saving Technology
| Online ECO Mode Efficiency |
Active PFC Compatibility
| Yes |
INPUT
Generator Compatibility
| Yes |
Nominal Input Voltage ( Vac )
| 200 |
| 208 |
| 220 |
| 230 |
| 240 |
Input Voltage Range ( Vac )
| 190 ~ 300 |
Adjustable Voltage Range ( Vac )
| 0~60% Load for 120 ~ 139 Vac |
| 0~70% Load for 140 ~ 159 Vac |
| 0~80% Load for 160 ~ 179 Vac |
| 0~90% Load for 180 ~ 189 Vac |
| 0~100% Load for 190 ~ 300 Vac |
Input Frequency ( Hz )
| 50 ± 10 |
| 60 ± 10 |
Input Frequency Detection
| Auto-sensing |
Rated Input Current ( A )
| 10 |
Input Power Factor
| 0.99 |
Input Connector Type
| IEC C14 | |
Detachable Power Cord Plug Type
| IEC C13 x 1 | |
Power Cord Length (ft.)
| 10 |
Power Cord Length (m.)
| 3 |
OUTPUT
Capacity (VA)
| 2000 |
Capacity (Watts)
| 1800 |
On Battery Waveform
| Pure Sine Wave |
On Battery Voltage(s) ( Vac )
| 200 ± 2 % |
| 208 ± 2 % |
| 220 ± 2 % |
| 230 ± 2 % |
| 240 ± 2 % |
Output Voltage Setting
| Configurable |
On Battery Frequency ( Hz )
| 50 ± 0.5% |
| 60 ± 0.5% |
Output Frequency Setting
| Configurable |
Power Factor
| 0.9 |
ECO Mode Voltage Tolerance
| ± 10 % |
| ± 15 % |
Overload Protection
| Internal Current Limiting, Circuit Breaker |
Overload Protection (Line Mode)
| 105~125% Load for 1 min, 125~150% Load for 10 sec |
Overload Protection (Battery Mode)
| 105~130% Load for 10 sec, 130~150% Load for 2 sec |
Overload Protection (Bypass Mode)
| Circuit Breaker |
Crest Factor
| 3 : 1 |
Harmonic Distortion (Linear Load)
| THD＜3% |
Harmonic Distortion (Non-linear Load)
| THD＜5% |
Internal Bypass
| Automatic Bypass, Manual Bypass |
Outlet(s) - Total
| 9 |
Outlet Type
| IEC C13 x 8 | |
| IEC C19 x 1 | |
Outlet(s) - Battery & Surge Protected
| 9 |
Outlet(s) - Critical Load (CL)
| 5 |
Outlet(s) - Non-Critical Load (NCL)
| 4 |
Typical Transfer Time ( ms )
| 0 |
BATTERY
Runtime at Half Load ( min )
| 20 |
Runtime at Full Load ( min )
| 6.5 |
Typical Recharge Time ( Hours )
| 5 |
Start On Battery
| Yes |
Smart Battery Management (SBM)
| Yes |
User-replaceable
| Yes |
Hot-swappable
| Yes |
Battery Type
| Sealed Lead-acid |
Battery Cartridge (RBP)
| RBP |
Battery Cartridge (RBP) Quantity ( pcs )
| 1 |
Battery Quantity (Each RBP) ( pcs )
| 6 |
Battery Voltage (Each RBP) ( V )
| 72 |
Compatible Extended Battery Module (EBM)
| BPE72V60ART2US |
Max. EBM Quantity ( pcs )
| 10 |
SURGE PROTECTION & FILTERING
Surge Suppression ( Joules )
| 1335 |
EMI/RFI Filtration
| Yes |
Phone/Network Protection RJ11/RJ45 (Combo)
| 1-in, 1-out |
MANAGEMENT & COMMUNICATIONS
LCD Panel
| Yes |
LCD Types
| Detachable LCD Panel |
LCD Information Display
| Operation Type, Power Status, Battery Status, Load Status, Fault & Warning, Other Information, Event & Log |
LCD Setting & Control
| Mode Setting, Alarm Setting, Input & Output, Battery Setting, Fault & Warning, Communication, Event & Log, Security Setting, Language |
LED Indicators
| Power On, Line Mode, Battery Mode, Bypass Mode, Battery Capacity, Low Battery, Overload, UPS Fault, Wiring Fault, Replace Battery |
HID Compliant USB Port(s)
| 1 |
Dry Contact (with Relay)
| Yes |
Emergency Power Off (EPO) Port
| Yes |
Audible Alarms
| Battery Mode, Low Battery, Overload, Overcharge, Overheat, UPS Fault, Replace Battery |
Management Cable ( pcs )
| Power Cord x1, USB Cable x1, Serial Cable x1, Phone Line x1 |
Power Management Software
| PowerPanel Business (Recommended) |
SNMP/HTTP Remote Monitoring
| Yes - with optional RMCARD205 |
PHYSICAL
Enclosure Construction
| Metal |
Color
| Black |
Rackmount Rail
| Yes |
Rackmount Ears
| Yes |
PHYSICAL SIZE - UPS MODULE
Dimensions (WxHxD) (in.)
| 17 x 3.5 x 23.6 |
Dimensions (WxHxD) (mm.)
| 433 x 88 x 600 |
Weight (lbs.)
| 70.4 |
Weight (kg.)
| 32 |
Installed Rack Height ( U )
| 2 |
SHIPPING DIMENSIONS
Dimensions (WxHxD) (in.)
| 22.2 x 9.4 x 34.6 |
Dimensions (WxHxD) (mm.)
| 565 x 240 x 880 |
Weight (lbs.)
| 86.9 |
Weight (kg.)
| 39.5 |
ENVIRONMENTAL
Operating Temperature (°F)
| 32 ~ 104 |
Operating Temperature (°C)
| 0 ~ 40 |
Operating Relative Humidity (Non-condensing) ( % )
| 0 ~ 90 |
Operating Elevation ( feet/meters )
| 0-9,843 feet (0-3,000 meters) |
Storage Temperature (°F)
| 5 ~ 113 |
Storage Temperature (°C)
| -15 ~ 45 |
Storage Relative Humidity (Non-condensing) ( % )
| 0 ~ 95 |
Storage Elevation ( feet/meters )
| 0-49,213 feet (0-15,000 meters) |
Online Thermal Dissipation ( BTU/hr )
| 759 |
Audible Noise at 1.5M from Surface of Unit ( dBA )
| 55 |
CERTIFICATIONS
Certifications
| CE, BSMI, C-Tick |
RoHS
| Yes |
WARRANTY
Product Warranty Period (Year)
| 2 |
Battery Warranty Period (Year)
| 2 |
| GTIN | 4712364142994 |
|---|
