CyberPower PR1500ELCD PRO 1500VA Tower UPS with LCD
Model
PR1500ELCD
| Location | Availability |
|---|---|
Online (Delivery) | Available from Supplier (2 to 3 Working Days) |
Notting Hill (Pickup) | Available from Supplier (2 to 3 Working Days) |
Preston (Pickup) | Available from Supplier (2 to 3 Working Days) |
West Melbourne (Pickup) | Available from Supplier (2 to 3 Working Days) |
$949.00
CyberPower PR1500ELCD PRO 1500VA Tower UPS with LCD
CyberPower PR1500ELCD Line-Interactive UPS, with seamless Pure Sine Wave, provides the best power protection available for office system devices including PCs, workstations, networking devices, and peripherals. It’s typically integrated in the back office, server room, and data center environment. The UPS can be locally managed via USB or serial ports, or remotely managed via an SNMP Card (an optional Remote Management Card), allowing administrators and users unsurpassed flexibility to remotely access each UPS through the network to perform real-time monitoring, UPS configurations, and scheduled system shutdowns by using PowerPanel Management software. The product is also certified to be interoperable and compatible with Cisco, which helps to achieve the best energy performance possible.
FEATURES
- Line-interactive UPS Topology
- Energy Saving Technology
- Active PFC Compatible
- Pure Sine Wave Output
- Automatic Voltage Regulation (AVR)
- Overload Protection
- Critical/Non-critical Load Outlets
- Hot-swappable Batteries
- Surge and Spike Protection
- EMI and RFI Filtration
- LCD Status Display
- Detachable LCD Panel
- USB Connectivity Port
- Serial Connectivity Port
- Emergency Power Off (EPO) Port
- PowerPanel® Management Software
- SNMP/HTTP Remote Management Capability (Optional)
- Tower Form Factor
TYPICAL APPLICATION
- SOHO Office
- Office
- Back Office
- Server Room
- Data Center
- Supermarket
- Factory
- Airport
- Train Station
- Home Theatre Systems
- Security Systems
- Surveillance Systems
- Telecom Devices
- Networking Devices
- NAS/Storage Devices
- Multimedia Devices
- Computers
- Workstations
GENERAL
Phase
| Single Phase |
UPS Topology
| Line-interactive |
Energy Saving Technology
| GreenPower UPS™ Bypass Technology |
Energy Star Qualified
| Yes |
Active PFC Compatibility
| Yes |
INPUT
Nominal Input Voltage ( Vac )
| 230 |
Input Voltage Range ( Vac )
| 151 ~ 301 |
Input Frequency ( Hz )
| 50 ± 3 |
| 60 ± 3 |
Input Frequency Detection
| Auto-sensing |
Rated Input Current ( A )
| 10 |
Input Connector Type
| IEC C14 |  |
Detachable Power Cord Plug Type
| AU |  |
| IEC C14 | |
Power Cord Length (ft.)
| 6 |
| 6 |
Power Cord Length (m.)
| 1.83 |
| 1.83 |
OUTPUT
Capacity (VA)
| 1500 |
Capacity (Watts)
| 1350 |
On Battery Waveform
| Pure Sine Wave |
On Battery Voltage(s) ( Vac )
| 230 ± 5% |
On Battery Frequency ( Hz )
| 50 ± 1% |
| 60 ± 1% |
Power Factor
| 0.9 |
Automatic Voltage Regulation (AVR)
| Double Boost, Single Buck |
Overload Protection
| Internal Current Limiting |
Outlet(s) - Total
| 8 |
Outlet Type
| IEC C13 x 8 |  |
Outlet(s) - Battery & Surge Protected
| 8 |
Outlet(s) - Critical Load (CL)
| 4 |
Outlet(s) - Non-Critical Load (NCL)
| 4 |
Typical Transfer Time ( ms )
| 4 |
BATTERY
Runtime at Half Load ( min )
| 17 |
Runtime at Full Load ( min )
| 4 |
Typical Recharge Time ( Hours )
| 8 |
Quick Recharge Time ( Hours )
| 3 |
Start On Battery
| Yes |
User-replaceable
| Yes |
Hot-swappable
| Yes |
Battery Type
| Sealed Lead-acid |
Battery Cartridge
| RBP0023 |
RBP Quantity ( pcs )
| 1 |
SURGE PROTECTION & FILTERING
Surge Suppression ( Joules )
| 405 |
EMI/RFI Filtration
| Yes |
MANAGEMENT & COMMUNICATIONS
LCD Panel
| Yes |
Detachable LCD Panel
| Yes |
LCD Information Display
| Operation Type , Power Status , Battery Status , Load Status , Fault & Warning , Other Information , Event & Log |
LCD Setting & Control
| Mode Setting , Alarm Setting , Input & Output , Battery Setting , Fault & Warning , Event & Log |
LED Indicators
| Power On , Line Mode , Battery Mode , UPS Fault , Replace Battery |
HID Compliant USB Port(s)
| 1 |
Serial Port
| Combo (RS232 + Dry Contact) |
Emergency Power Off (EPO) Port
| Yes |
Audible Alarms
| Battery Mode , Low Battery , Overload , UPS Fault |
Management Cable ( pcs )
| Power Cord x2 , USB Cable x1 , EPO Cable x1 |
Power Management Software
| PowerPanel® Business |
SNMP/HTTP Remote Monitoring
| Yes - with optional RMCARD205 |
PHYSICAL
Form Factor
| Tower |
Enclosure Construction
| Metal |
Color
| Black |
PHYSICAL SIZE - UPS MODULE
Dimensions (WxHxD) (in.)
| 6.69 x 8.70 x 17.01 |
Dimensions (WxHxD) (mm.)
| 170 x 221 x 432 |
Weight (lbs.)
| 55.34 |
Weight (kg.)
| 25.1 |
SHIPPING DIMENSIONS
Dimensions (WxHxD) (in.)
| 12.44 x 14.17 x 22.80 |
Dimensions (WxHxD) (mm.)
| 316 x 360 x 579 |
Weight (lbs.)
| 60.47 |
Weight (kg.)
| 27.43 |
ENVIRONMENTAL
Operating Temperature (°F)
| 32 ~ 104 |
Operating Temperature (°C)
| 0 ~ 40 |
Operating Relative Humidity (Non-condensing) ( % )
| 0 ~ 95 |
Operating Elevation ( feet/meters )
| 0-10,000 feet (0-3,000 meters) |
Storage Temperature (°F)
| 5 ~ 113 |
Storage Temperature (°C)
| -15 ~ 45 |
Storage Relative Humidity (Non-condensing) ( % )
| 0 ~ 95 |
Storage Elevation ( feet/meters )
| 0-50,000 feet (0-15,000 meters) |
Online Thermal Dissipation ( BTU/hr )
| 113 |
CERTIFICATIONS
Certifications
| CE , EAC , RCM |
RoHS
| Yes |
WARRANTY
Product Warranty Period (Year)
| 3 |
Battery Warranty Period (Year)
| 2 |
Connected Equipment Guarantee
| 100,000 AUD ; 3 years |
| GTIN | 4712364144202 |
|---|
