ESSENTIALS
|
|
|
Product Collection
|
Intel® Core™ Ultra Processors (Series 2)
|
|
Code Name
|
Products formerly Arrow Lake
|
|
Vertical Segment
|
Desktop
|
|
Processor Number
|
225F
|
|
Overall Peak TOPS (Int8)
|
19
|
|
CPU SPECIFICATIONS
|
|
|
Total Cores
|
10
|
|
# of Performance-cores
|
6
|
|
# of Efficient-cores
|
4
|
|
Total Threads
|
10
|
|
Max Turbo Frequency
|
4.9 GHz
|
|
Performance-core Max Turbo Frequency
|
4.9 GHz
|
|
Efficient-core Max Turbo Frequency
|
4.4 GHz
|
|
Performance-core Base Frequency
|
3.3 GHz
|
|
Efficient-core Base Frequency
|
2.7 GHz
|
|
Cache
|
20 MB Intel® Smart Cache
|
|
Total L2 Cache
|
22 MB
|
|
Processor Base Power
|
65 W
|
|
Maximum Turbo Power
|
121 W
|
|
Intel® Deep Learning Boost (Intel® DL Boost) on CPU
|
Yes
|
|
AI Software Frameworks Supported by CPU
|
OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN
|
|
CPU Lithography
|
TSMC N3B
|
|
MEMORY SPECIFICATIONS
|
|
|
Max Memory Size (dependent on memory type)
|
192 GB
|
|
Memory Types
|
Up to DDR5 6400 MT/s
|
|
Max # of Memory Channels
|
2
|
|
NPU SPECIFICATIONS
|
|
|
NPU Nam
|
Intel® AI Boost
|
|
NPU Peak TOPS (Int8)
|
13
|
|
Sparsity Support
|
Yes
|
|
Windows Studio Effects Support
|
Yes
|
|
AI Software Frameworks Supported by NPU
|
OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN
|
|
EXPANSION OPTIONS
|
|
|
Direct Media Interface (DMI) Revision
|
4
|
|
Max # of DMI Lanes
|
8
|
|
Intel® Thunderbolt™ 4
|
Yes
|
|
Scalability
|
1S Only
|
|
PCI Express Revision
|
5.0 and 4.0
|
|
PCI Express Configurations
|
Up to 1x16+2x4, 2x8+2x4, 1x8+4x4
|
|
Max # of PCI Express Lanes
|
24
|
|
PACKAGE SPECIFICATIONS
|
|
|
Sockets Supported
|
FCLGA1851
|
|
Thermal Solution Specification
|
PCG 2022C
|
|
Max Operating Temperature
|
105 °C
|
|
ADVANCED TECHNOLOGIES
|
|
|
Intel® Volume Management Device (VMD)
|
Yes
|
|
Intel® Gaussian & Neural Accelerator
|
3.5
|
|
Intel® Thread Director
|
Yes
|
|
Intel® Speed Shift Technology
|
Yes
|
|
Intel® Turbo Boost Technology
|
2.0
|
|
Intel® 64
|
Yes
|
|
Instruction Set
|
64-bit
|
|
Instruction Set Extensions
|
Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
|
|
Idle States
|
Yes
|
|
Enhanced Intel SpeedStep® Technology
|
Yes
|
|
Thermal Monitoring Technologies
|
Yes
|
|
SECURITY & RELIABILITY
|
|
|
Intel® Standard Manageability (ISM)
|
Yes
|
|
Intel® Control-Flow Enforcement Technology
|
Yes
|
|
Intel® AES New Instructions
|
Yes
|
|
Secure Key
|
Yes
|
|
Intel® Trusted Execution Technology
|
Yes
|
|
Execute Disable Bit
|
Yes
|
|
Intel® OS Guard
|
Yes
|
|
Intel® Boot Guard
|
Yes
|
|
Mode-based Execute Control (MBEC)
|
Yes
|
|
Intel® Virtualization Technology (VT-x)
|
Yes
|
|
Intel® Virtualization Technology for Directed I/O (VT-d)
|
Yes
|
|
Intel® VT-x with Extended Page Tables (EPT)
|
Yes
|
