QNAP TS-h3087XU-RP-E2378-64G 30-Bay 4U Rackmount NAS Intel Xeon E-23786 & 64GB RAM
| Location | Availability |
|---|---|
Online (Delivery) | Available from Supplier (2 to 7 Working Days) |
Notting Hill (Pickup) | Available from Supplier (2 to 7 Working Days) |
Preston (Pickup) | Available from Supplier (2 to 7 Working Days) |
West Melbourne (Pickup) | Available from Supplier (2 to 7 Working Days) |
SPECIFICATIONS
|
CPU |
Intel® Xeon® E-2378 8C 16T 2.6GHz, up to 4.8GHz |
|
CPU Architecture |
64-bit x86 |
|
Floating Point Unit |
✓ |
|
Encryption Engine |
✓ (AES-NI) |
|
System Memory |
64 GB ECC DDR4 (4 x 16 GB) |
|
Maximum Memory |
128GB (4 x 32 GB) |
|
Memory Slot |
4 x ECC UDIMM DDR4 For dual-DIMM configuration, you must use a pair of identical DDR4 modules. |
|
Flash Memory |
5GB (Dual boot OS protection) |
|
Drive Bay |
30 (24 x 3.5-inch SATA + 6 x 2.5-inch SATA) |
|
Drive Compatibility |
3.5-inch bays: |
|
Hot-swappable |
✓ |
|
SSD Cache Acceleration Support |
✓ |
|
GPU pass-through |
✓ |
|
2.5 Gigabit Ethernet Port (2.5G/1G/100M) |
2 (2.5G/1G/100M) |
|
10 Gigabit Ethernet Port |
2 x 10GBASE-T (10G/5G/2.5G/1G/100M) |
|
Wake on LAN (WOL) |
✓ |
|
PCIe Slot |
3 (2 x Gen4 x4 +1 x Gen 4 x8)
Card dimensions for PCIe slot 1：260 x 131.15 x 54.16 mm / 10.24 x 5.16 x 2.13 inches |
|
USB 3.2 Gen 2 (10Gbps) Port |
4 x Type-A USB 3.2 Gen 2 5V/1A 10Gbps |
|
Form Factor |
4U Rackmount |
|
LED Indicators |
Status (Green/Red) |
|
Buttons |
Power, Reset |
|
Dimensions (HxWxD) |
176.2 × 441.6 × 630.2 mm |
|
Weight (Net) |
21.78 kg |
|
Weight (Gross) |
29.63 kg |
|
Operating Temperature |
0 - 40 °C (32°F - 104°F) |
|
Storage Temperature |
-20 - 70°C (-4°F - 158°F) |
|
Relative Humidity |
5~95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
|
Power Supply Unit |
2 x 800W PSU |
|
Power Consumption: HDD Sleep Mode |
149.92 W |
|
Power Consumption: Operating Mode, Typical |
219.03 W |
|
Fan |
4 x 80mm, 12VDC |
|
Max. Number of Concurrent Connections (CIFS) |
11000 |
| GTIN | 5050914227982 |
|---|
