Startech PEX8S1050 8 Port PCI Express RS232 Serial Adapter
Model
PEX8S1050
| Location | Availability |
|---|---|
Online (Delivery) | Available from Supplier (2 to 7 Working Days) |
Notting Hill (Pickup) | Available from Supplier (2 to 7 Working Days) |
Preston (Pickup) | Available from Supplier (2 to 7 Working Days) |
West Melbourne (Pickup) | Available from Supplier (2 to 7 Working Days) |
$379.00
8-Port PCI Express RS232 Serial Adapter Card - PCIe RS232 Serial Card - 16C1050 UART - Multiport Serial DB9 Controller/Expansion Card - 15kV ESD Protection - Windows & Linux
Add eight RS-232 DB9 serial ports to your desktop computer, through a PCIe expansion card slots. This PCI express serial card, with 8-port breakout cable, provides you with multiple ports to connect a wide variety of serial peripherals, at speeds of up to 921.4Kbps.
Connect your Peripherals with 8 Serial Ports
The PCI express serial port card makes it easy to add serial ports to connect your peripherals including printers, scanners, credit/debit card readers, PIN pads and modems, industrial controls and more. The 8 port PCIe serial card includes a breakout cable - with 8 DB9 connectors.
Maximum Compatibility
With broad OS support, including for Windows and Linux, this PCI Express card is easy to integrate into mixed environments.
| Warranty Information | Warranty | Lifetime |
|---|---|---|
| Connector(s) | 1 - Connector Type(s) | PCI Express x1 |
| 8 - External Ports | DB-9 (9 pin, D-Sub) | |
| Environmental | Operating Temperature | 0°C to 55°C (32°F to 131°F) |
| Storage Temperature | -40°C to 75°C (-40°F to 167°F) | |
| Humidity | 5~95% RH | |
| Hardware | Ports | 8 |
| Interface | Serial | |
| Bus Type | PCI Express | |
| Card Type | Standard Profile | |
| Port Style | Dongle (Included) | |
| Industry Standards | 16C1050 UART | |
| Chipset ID | ASMedia - ASM1083 | |
| System Base - SB16C1058PCI | ||
| Packaging Information | Package Height | 2.6 in [65.0 mm] |
| Package Length | 11.4 in [29.0 cm] | |
| Shipping (Package) Weight | 23.7 oz [672.0 g] | |
| Package Width | 7.5 in [19.0 cm] | |
| Performance | Serial Protocol | RS-232 |
| ESD Protection | +/-15kV (Air) | |
| Max Baud Rate | 921.6 Kbps | |
| Data Bits | 5, 6, 7, 8 | |
| ESD Protection | +/-8kV (Contact) | |
| FIFO | TX: 1-255 Byte RX: 1-255 Byte * Depending on mode and configurations |
|
| Flow Control | Software (XON/XOFF), Hardware (RTS/CTS), and Xoff Re-Transmit function | |
| Parity | None, Even, or Odd | |
| Stop Bits | 1, 1.5, 2 | |
| General Specifications | Power on Pin 9: 12V DC, 5V DC or None | |
| MTBF | 160,013 hours | |
| Physical Characteristics | Color | Yellow |
| Product Height | 4.7 in [12.0 cm] | |
| Product Length | 4.1 in [10.5 cm] | |
| Weight of Product | 2.6 oz [74.0 g] | |
| Product Width | 0.6 in [16.0 mm] | |
| Material | Steel | |
| Cable Length | 18.9 in [48 cm] | |
| Software | OS Compatibility | Windows® CE 5.0, 98SE, 2000, XP, Vista, 7, 8, 8.1, 10 Windows Server® 2003, 2008 R2, 2012, 2016, 2019 Linux 2.4.18 to 4.16.x LTS Versions only |
| What's in the Box | 1 - Included in Package | PCIe Serial Card |
| 18 in [48 cm] DB62 to 8 Port DB9 Breakout Cable | ||
| Full Profile Bracket (Installed) | ||
| Quick Start Guide | ||
| 8 - Included in Package | Optional DB9 Connector Hex Nut Pairs |
| GTIN | 0065030888295 |
|---|
