Synology DS723+ DiskStation 2-Bay Scalable NAS

Synology DS723+ DiskStation 2-Bay Scalable NAS

Model
DS723+
Be the first to review this product
LocationAvailability
Online (Delivery)
End of Life
Notting Hill (Pickup)
End of Life
Preston (Pickup)
End of Life
West Melbourne (Pickup)
End of Life
$682.00
Add to Wish List Add to Compare
Synology DS723+ DiskStation 2-Bay Scalable NAS

ds723+

Specifications

CPU CPU Model AMD Ryzen R1600
  CPU Quantity 1
  CPU Architecture 64-bit
  CPU Frequency 2-core 2.6 (base) / 3.1 (turbo) GHz
  Hardware Encryption Engine (AES-NI)  ✓
Memory System Memory 2 GB DDR4 ECC
  Memory Module Pre-installed 2 GB (2 GB x 1)
  Total Memory Slots 2
  Maximum Memory Capacity 32 GB (16 GB x 2)
  Notes
  • Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
  • Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
  • For more information about the recommended memory configurations, please check the Hardware Installation Guide of your Synology product.
Storage Drive Bays 2
  Maximum Drive Bays with Expansion Unit 7 (DX517 x 1)
  M.2 Drive Slots 2 (NVMe)
  Compatible Drive Type* (See all supported drives)
  • 3.5" SATA HDD
  • 2.5" SATA SSD
  • M.2 2280 NVMe SSD
  Hot Swappable Drive*  ✓
  Notes
  • The hot swappable drive feature is not supported by M.2 SSD slots.
  • "Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
External Ports RJ-45 1GbE LAN Port* 2 (with Link Aggregation / Failover support)
  USB 3.2 Gen 1 Port* 1
  eSATA Port 1
  Notes
  • This device's 1GbE LAN ports have a maximum transmission unit (MTU) size of 1,500 bytes.
  • The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019.
PCIe PCIe Expansion 1 x Gen3 x2 network upgrade slot
File System Internal Drives
  • Btrfs
  • EXT4
  External Drives
  • Btrfs
  • EXT4
  • EXT3
  • FAT
  • NTFS
  • HFS+
  • exFAT
Appearance Size (Height x Width x Depth) 166 mm x 106 mm x 223 mm
  Weight 1.51 kg
Others System Fan 92 mm x 92 mm x 1 pcs
  Fan Speed Mode
  • Full-Speed Mode
  • Cool Mode
  • Quiet Mode
  Brightness Adjustable Front LED Indicators  ✓
  Power Recovery  ✓
  Noise Level* 20.7 dB(A)
  Scheduled Power On / Off  ✓
  Wake on LAN / WAN  ✓
  Power Supply Unit / Adapter 65 W
  AC Input Power Voltage 100V to 240V AC
  Power Frequency 50/60 Hz, Single Phase
  Power Consumption 21.07 W (Access)
8.62 W (HDD Hibernation)
  British Thermal Unit 71.85 BTU/hr (Access)
29.39 BTU/hr (HDD Hibernation)
  Notes
  • For more information on how power consumption is measured, refer to this article.
  • Noise testing was conducted with the Synology system fully installed with Synology SATA HDDs and in an idle state. Two GRAS 40AE microphones are placed at a 1 m distance from the front and rear of the device. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
Temperature Operating Temperature 0°C to 40°C (32°F to 104°F)
  Storage Temperature -20°C to 60°C (-5°F to 140°F)
  Relative Humidity 5% to 95% RH
Certification
  • FCC
  • CE
  • BSMI
  • VCCI
  • RCM
  • UKCA
  • EAC
  • CCC
  • KC
Warranty 3-year hardware warranty, extendable to 5 years with Extended Warranty Plus
  Notes
  • Availability varies by region. Before purchasing, please visit the official web pages of EW201/202 and Extended Warranty Plus for a list of eligible regions.
  • The warranty period starts from the purchase date as stated on your purchase receipt.
Environment RoHS Compliant
Packaging Content
  • Main Unit X 1
  • Accessory Pack X 1
  • AC Power Adapter X 1
  • AC Power Cord X 1
  • RJ-45 LAN Cable X 2
  • Quick Installation Guide X 1
Optional Accessories
  • DDR4 ECC SODIMM: D4ES02-4G/D4ES02-8G/D4ES01-16G
  • Expansion Units: DX517
  • 3.5" SATA HDD: HAT5300
  • 2.5" SATA SSD: SAT5210
  • M.2 2280 NVMe SSD: SNV3410
  • 10GbE Network Upgrade Module: E10G22-T1-Mini
  • VisualStation: VS360HD
  • Surveillance Device License Pack
