Tenda O8 5GHz 23dBi 11ac Outdoor CPE
| Location | Availability |
|---|---|
Online (Delivery) | Available from Supplier (2 to 7 Working Days) |
Notting Hill (Pickup) | Available from Supplier (2 to 3 Working Days) |
Preston (Pickup) | Available from Supplier (2 to 3 Working Days) |
West Melbourne (Pickup) | Available from Supplier (2 to 3 Working Days) |
O8 5GHz 23dBi 11ac Outdoor CPE is designed to PtP and PtMP solutions for private ISP wireless connectivity, CCTV surveillance and data transmission. It features with 23dBi directional vertical polarization antenna to provide an efficient way to pick up and maintain a stable long-distance connectivity up to 20km. Adopt of auto-bridging technology, two CPE can connect to each other automatically to make it easy to setup.
SPECIFICATIONS
|
HARDWARE |
|
|
Frequency Range |
5GHz |
|
Compliant Standards |
IEEE 802.11a/n/ac |
|
Maximum Wireless Rate |
433Mbps |
|
Interfaces |
1*10/100Mbps Ethernet Port |
|
Antenna |
Vertical Polarization |
|
Antennas Gain |
23dBi |
|
Antenna Beamwidth |
Vertical: 10° Elevation: 10° |
|
GND |
/ |
|
Reset Button |
1 |
|
Power Consumption |
5.5W |
|
Waterproof Level |
IP65 |
|
LED Indicator |
PoE/LAN,LED1,LED2,LED3 |
|
Power Method |
12V1A Passive PoE |
|
Lightning Protection |
6000V |
|
Passive PoE |
Passive power over ethenet via PoE/LAN( 4,5pins,-7,8pins ) Voltage range: 9-35V DC |
|
Reception Sensitivity |
11a 6Mbps -95dBm±1.5dBm 11n MCS7 HT20 -72dBm±1.5dBm 11ac MCS9 HT80 -64dBm±1.5dBm |
|
SOFTWARE |
|
|
TDMA |
Support |
|
Operating mode |
AP/Station/WISP/P2MP/WDS Repeater/Router |
|
Enable/Disable Wireless Radio |
Support |
|
SSID Hidden |
Support |
|
Wireless Client isolation |
Support |
|
SSID Isolation |
Support |
|
Channel Bandwidth |
20/40/80MHz |
|
Channel Shift |
Support |
|
Wireless Access Control |
Support |
|
Weak Signal Client Limitation |
Support |
|
Transmission Power |
Adjustable power by 1dBm |
|
WMM Capable |
Support |
|
APSD Capable |
Support |
|
Wireless Security |
64/128 WEP,WPA-PSK,WPA2-PSK,WPA |
|
Transparent Bridge |
Support |
|
VLAN Tagging for SSID |
Support |
|
DHCP Server |
Support |
|
VPN Pass-Through |
PPTP,L2TP |
|
Remote Web access |
Support |
|
Schedule Reboot |
Support |
|
Page Timeout |
Support |
|
Ping Watchdog |
Support |
|
Dyndns |
noip, dyndns.org |
|
Network Diagnoses |
Ping, Traceroute, Signal Scan |
|
Time and Date Setting |
Support |
|
Firmware upgrade |
Support |
|
Backup/Restore Configuration |
Support |
|
Username Managerment |
Support |
|
System Logs |
Support |
|
Managed By Controller |
PC Software -- CPE Assistant |
|
OTHERS |
|
|
Package Contents |
1*5GHz 23dBi 11ac Outdoor CPE O8 1*Power Adapter 1*PoE Injector 1*Quick Installation Guide |
|
Operation Temperature |
-30℃ ~ 60℃ |
|
Storage Temperature |
-40℃ ~ 70℃ |
|
Operating Humidity |
10%~90% non-condensing |
|
Storage Humidity |
10%~90% non-condensing |
|
Default login IP |
192.168.2.1 |
|
Default Login Username |
admin |
|
Default Login Password |
admin |
|
Certification |
FCC/CE/RoHS |
| GTIN | 6932849435023 |
|---|
