TP-Link VIGI NVR1008H-8MP 8 Channel PoE+ Network Video Recorder
| Location | Availability |
|---|---|
Online (Delivery) | Available from Supplier (2 to 3 Working Days) |
Notting Hill (Pickup) | Available from Supplier (2 to 7 Working Days) |
Preston (Pickup) | Available from Supplier (2 to 7 Working Days) |
West Melbourne (Pickup) | Available from Supplier (2 to 7 Working Days) |
SPECIFICATIONS
|
DECODING |
|
|
Decoding Format |
H.265+/H.265/ H.264+/H.264 |
|
Live View/Playback Resolution |
8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
|
Synchronous Playback |
8 Channel |
|
Capability |
2-ch @ 8MP, 4-ch @ 4MP, 8-ch @ 2MP |
|
NETWORK |
|
|
Protocol |
TCP/IP, DHCP, DNS, NTP, UPnP |
|
Incoming Bandwidth |
80 Mbps |
|
Outgoing Bandwidth |
60 Mbps |
|
INTERFACES |
|
|
Network Interface |
1 RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface |
|
USB Interface |
2× USB 2.0 |
|
HARD DISK |
|
|
SATA |
1 SATA Interface |
|
Capacity |
Up to 10 TB |
|
GENERAL |
|
|
Package Contents |
VIGI Network Video Recorder Power Adapter HDD Screws Quick Installation Guide |
|
Operating Temperature |
-10–55 °C |
|
Dimensions( W X D X H ) |
294 × 180 × 44 mm |
|
PoE |
Standard: 802.3af/at PoE Ports: Ports 1-8 PoE Budget: 113 W |
|
External Power Supply |
53.5V DC/2.43 A |
|
Power Consumption |
4.82 W (without disk) |
|
VIDEO/IMAGE |
|
|
Video Input |
8-Channel IP Video Input, up to 8 MP Resolution |
|
Recording Resolution |
8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF |
|
HDMI Output Resolution |
1 Channel, Resolution: 3840x2160/30Hz,1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1024x768/60Hz, 1280x720/60Hz |
|
VGA Output Resolution |
1 Channel, Resolution: 1920x1080/60Hz,1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
|
OTHERS |
|
|
Notes |
Rack-mounting accessories are not included. Calculations based on laboratory testing using VIGI cameras. §PoE budget calculations are based on laboratory testing. Actual PoE power budget is not guaranteed and will vary as a result of client limitations and environmental factors. △Some features may operate sub-optimally due to compatibility issues. For best performance, we recommend using VIGI NVR with VIGI cameras. *Fewer or no channels may be available for playback if the total resolution is 16MP. **Calculations based on laboratory testing using a 3MP VIGI camera. Actual performance may vary according to the amount of activity recorded, resolution, and other variables. |
| GTIN | 4897098688762 |
|---|
