Ubiquiti PBE-5AC-500 PowerBeam M5 AC 500 27dBi 5GHz 802.11ac 2x2 MIMO Antenna

DIMENSIONS

Radome Excluded

Radome Included

520 x 520 x 308 mm (20.47 x 20.47 x   12.13")

525 x 525 x 315 mm (20.67 x 20.67 x   12.40")

WEIGHT

Radome Excluded

Radome Included

2.35 kg (5.18 lb)

3.15 kg (6.95 lb)

POWER SUPPLY

24V, 0.5A Gigabit PoE

MAX. POWER CONSUMPTION

8.5W

POWER METHOD

Passive PoE (Pairs 4, 5+; 7, 8 Return)

SUPPORTED VOLTAGE RANGE

20-26VDC

OPERATING FREQUENCY

5150 - 5875 MHz

GAIN

27 dBi

NETWORKING INTERFACE

(1) 10/100/1000 Ethernet Port

PROCESSOR SPECS

Atheros MIPS 74Kc, 720 MHz

MEMORY

128 MB DDR2, 16 MB Flash

LEDS

(1) Power, (1) LAN, (4) WLAN

SIGNAL STRENGTH LEDS

Software-Adjustable to Correspond to Custom   RSSI Levels

MAX. VSWR

1.5:1

CHANNEL SIZES

PtP Mode

PtMP Mode

10/20/30/40/50/60/80 MHz

10/20/30/40 MHz

POLARISATION

Dual Linear

ENCLOSURE

Outdoor UV Stabilized Plastic

MOUNTING

Pole-Mount (Kit Included)

WIND LOADING

264.6 N @ 96 km/h (60 lbf @ 60 mph)

WIND SURVIVABILITY

96 km/h (60 mph)

ESD/EMP PROTECTION

Air: ± 24 kV, Contact: ± 24 kV

OPERATING TEMPERATURE

-40 to 70° C (-40 to 158° F)

OPERATING HUMIDITY

5 to 95% Noncondensing

WIRELESS APPROVALS

FCC, IC, CE

ROHS COMPLIANCE

Yes

SALT FOG TEST

IEC 68-2-11 (ASTM B117), Equivalent:   MIL-STD-810 G Method 509.5

VIBRATION TEST

IEC 68-2-6

TEMPERATURE SHOCK TEST

IEC 68-2-14

UV TEST

IEC 68-2-5 at 40° C (104° F), Equivalent: ETS   300 019-1-4

WIND DRIVEN RAIN TEST

ETS 300 019-1-4, Equivalent: MIL-STD-810 G   Method 506.5
